WARNING: If you are using the this hinge in furniture that can be accessed by small children it should be noted that it is possible for small fingers to get in-between the working mechanism of the hinge. In these cases a 155° hinge could be used as an alternative or all relevant doors should be fitted with child safety latches. This warning should be passed on subsequent users of the product.

Opening: 170

Finish: Nickel

Boss: Screw on

Overlay: Full

Box Qty: 125

Additional Features / Properties

Cover cap type: 80.6507

Type of side adjustment: With screw

Type of depth adjustment: convenient with spiral screw

Item package: 1 piece

Maximum drilling distance: 8 mm

Minimum drilling distance: 3 mm

Fixed dimension / factory setting: 11 mm

Weight: 1703.24 kg

collision measurement (hinge arm height): 65 mm

Cranking: Overlay application

Country of origin: AT

Delivery unit: 25

Height Outside carton: 26.4 cm

Layer quantity: 500

Lenght Outside carton: 59.7 cm

Palette height without transport equipment: 79 cm

Pallet quantity: 1500

Replenishment lead time: 2 day

Transport time: 2 day

Volume/1000: 480.32 dm³

Weight (tare)/1000: 16.523 kg

Width Outside carton: 37.5 cm

mounting plate system: CLIP

Colour/surface: Nickel plated

Opening angle: 170

Closing mechanism: unsprung

SAP-Distribution status: 20 - On sale

SAP - Program allocation: SP - Stock Program

Side adjustment: +/- 2 mm mm

Depth adjustment: + 3/- 2 mm mm

Boss assembly: screw-on

Boss material: Steel boss

boss finish: Nickel plated

Boss adjustment: none

door materia: Wood

Gap: 1.5 mm

Weight based on: 10000 Piece

application: wide angle hinge

packaging: Commercial packing

Packaging unit:  125

Packaging unit:  2125

Packaging unit: 30

Customs tariff number: 8302100090
